2.2021/9/26
OE of HUST
2
3.1 Introduction
3.1.1 Components of Optical Transmitters
Binary to single
Coding/line coding
Modulator
Optical Source
Driving Circuit
PCM
Channel coupler
Optical signal output
3.2021/9/26
OE of HUST
3
Biased current
Modulation current
(≥10Gb/s)
Modulation current
Biased current
(≤2.5Gb/s)
(a) Direct Modulation
(b) External Modulation
4.2021/9/26
OE of HUST
4
1. stability : power & wavelength
2. reliability > 25 years (Pout to Pout /2)
3. small emissive area compatible with fiber core dimensions
4. right wavelength range
0.85 µm : GaAlAs/GaAs
1.31 µm, 1.55 µm : InP/InGaAsP
5. narrow linewidth → Dispersion
6. direct modulation
7. high efficiency: MQW-LD Ith ~ 10 mA
3.1.2 Requirements for Optical Source
7.2021/9/26
OE of HUST
7
3.2.1 Three fundamental transition processes
1. Spontaneous Emission → LED
2. Stimulated Emission → LD, SOA
3. Stimulated Absorption → PIN / APD
3.2 Basic Concepts
Light Emission
8.2021/9/26
OE of HUST
8
3.2.2 Emission and Absorption Rates
E2
N2
N1
E1
spectral density of the
electromagnetic energy
In thermal equilibrium :
kB: Boltzmann Constant
T: Absolute Temperature
According to Boltzmann Statistics :
9.2021/9/26
OE of HUST
9
In the visible or near-infrared region at room temperature
thermal equilibrium laser operation
N2>N1, Rstim>Rabs (population inversion)
Conclusion:
10.2021/9/26
OE of HUST
10
Energy bands in semiconductor
11.2021/9/26
OE of HUST
11
The occupation probability for electrons in the conduction and
valence bands is given by the Fermi-Dirac distributions:
Efc, Efv are the Fermi levels in conduction band and valence band respectively
12.2021/9/26
OE of HUST
12
joint density of states :
the number of states per unit
volume per unit energy range
Eg: bandgap
mr: reduced mass
mc, mv: effective masses of electrons & holes in
conduction and valence bands, respectively
13.2021/9/26
OE of HUST
13
Population-inversion condition:
in thermal equilibrium:
pumping energy into the semiconductor from an external energy source
a forward-biased p-n junction
14.2021/9/26
OE of HUST
14
1. Type of semiconductor
Intrinsic semiconductor:
undoped, Fermi level, lying in the middle of the bandgap
n-type semiconductor:
Fermi level moves toward the conduction band as the dopant concentration increases
p-type semiconductor:
Fermi level moves toward the valence band as the dopant concentration increases
3.2.3 p-n junctions
15.2021/9/26
OE of HUST
15
n-type
Intrinsic
p-type
forward biased
16.2021/9/26
OE of HUST
16
Forward biased p-n junctions
(a) in thermal equilibrium
(b) under forward biased
2.
under forward biased:
built-in electric field is reduced
diffusion of electrons and holes across the junction
generate light through spontaneous emission or stimulated emission
17.2021/9/26
OE of HUST
17
P
N
18.2021/9/26
OE of HUST
18
3. (1) Homojunction:
the same semiconductor material
wide region for electron-hole recombination
difficult to realize high carrier densities
(2) Heterojunction: different bandgaps
(3) Double-heterojunction: sandwiching a thin layer between the
p-type and n-type layers such that the bandgap of the sandwiches layer is smaller than the layer surrounding it.
Homojunction & heterojunction
19.2021/9/26
OE of HUST
19
Double-heterojunction
20.2021/9/26
OE of HUST
20
21.2021/9/26
OE of HUST
21
Active layer: light is generated inside it as a result of electron-hole recombination
higher density of carriers →higher index → waveguide (1D)
Heterojunction: confinement of charge carriers & the optical field
0.85µm: cladding/active: GaAlAs/GaAs
1.31µm, 1.55µm: cladding/active: InP/InGaAsP
22.2021/9/26
OE of HUST
22
1. electron-hole recombination
3.2.4 Nonradiative Recombination
Trap of defects
Surface recombination
Auger
Nonradiative recombination
23.2021/9/26
OE of HUST
23
2. internal quantum efficiency
Rrr : radiative recombination rate
Rnr : nonradiative recombination rate
Rtot : totale recombination rate
τ : recombination time
24.2021/9/26
OE of HUST
24
Nonradiative recombination is harmful to devices!
positive feed back
E
0
E
0
k1
k2
(1) direct-bandgap (GaAs, InP)
(2) indirect-bandgap (Si, Ge)
25.2021/9/26
OE of HUST
25
3. carrier lifetime
A : defects & traps
B : spontaneous radiative
C : Auger
26.2021/9/26
OE of HUST
26
Quality of the heterojunction interface depends on the lattice constant of the two materials. (matching !)
3.2.5 Semiconductor Materials
ternary compound
quaternary compound
0.85µm: GaAlAs/GaAs (cladding/active)
1.31µm, 1.55µm: InP/InGaAsP (cladding/active)
41.2021/9/26
OE of HUST
41
3.4 Semiconductor lasers (Laser Diodes)
Advantages of stimulated emission compared with spontaneous emission of semiconductor materials
emitting high power (to 100mW)
narrow angular spread
narrow spectral width
direct modulation at high frequency (to 10GHz, because is small)
42.2021/9/26
OE of HUST
42
Components of Semiconductor Lasers
43.2021/9/26
OE of HUST
43
z=0
z=L
Injection current
Gain medium
Resonant cavity
Resonant cavity
44.2021/9/26
OE of HUST
44
3.4.1 Optical Gain
Peak gain of medium:
when
: differential gain (gain cross section)
: injection carrier density
: transparent carrier density
: threshold carrier density
NT is equal to Nth ?
45.2021/9/26
OE of HUST
45
Figure 3.9: (a) Gain spectrum of a 1.3-μm InGaAsP laser at several carrier densities N. (b) Variation of peak gain gp with N. The dashed line shows the quality of a linear fit in the high gain region.
Blue or red shifting of peak wavelength vs. injected current ?
46.2021/9/26
OE of HUST
46
3.4.2 Feedback and Laser Threshold
Feedback
R1
R2
n0=1
n
47.2021/9/26
OE of HUST
47
Threshold
48.2021/9/26
OE of HUST
48
Amplitude condition
Phase condition
spacing of oscillating frequency
oscillating frequency
threshold gain
49.2021/9/26
OE of HUST
49
MLM
Loss
SLM
50.2021/9/26
OE of HUST
50
3.4.3 LD Structures
Broad-area LD
Figure 3.12: A broad-area semiconductor laser. The active layer (hatched region) is sandwiched between p-type and n-type cladding layers of a higher-bandgap material.
light-confinement mechanism in the direction perpendicular to the junction plane introduced by double heterostructure
51.2021/9/26
OE of HUST
51
no such light-confinement mechanism in the lateral direction parallel to the junction plane.
the light generated spreads over the entire width of the laser.
relatively high threshold current and a spatial pattern that is highly elliptical and that changes in an uncontrollable manner with the current.
52.2021/9/26
OE of HUST
52
Gain-guided semiconductor lasers
Figure 3.13: Cross section of two stripe-geometry laser structures used to design gain-guided semiconductor lasers and referred to as (a) oxide stripe and (b) junction stripe.
Stripe lasers
53.2021/9/26
OE of HUST
53
solve the light-confinement problem by limiting current injection over a narrow stripe.
the spot size is not stable as the laser power is increased
54.2021/9/26
OE of HUST
54
Index-guided semiconductor lasers
Figure 3.14: Cross section of two index-guided semiconductor lasers: (a) ridge-waveguide structurefor weak index guiding; (b) etched-mesa buried heterostructure for strong index guiding.
65.2021/9/26
OE of HUST
65
3.5 Laser Characteristics
3.5.1 CW Characteristics
For a single-mode laser, the rate equations:
P, N: number of photons & carriers
Net rate of stimulated emission—optical gain:
Photon lifetime:
CW operation
66.2021/9/26
OE of HUST
66
threshold current
Spontaneous emission
Stimulated emission
P-I Curves
67.2021/9/26
OE of HUST
67
Ith (T)
T0: characteristic temperature
GaAs: T0=120K, InGaAsP: T0=50 ~ 70K
Bending of P-I curves
Rnr: mainly depending on Auger recombination in InGaAsP LD
Solution: built-in thermoelectric cooler used to deal with temperature
sensitivities of InGaAsP Lasers
68.2021/9/26
OE of HUST
68
Threshold of current & carrier
For I>Ith
threshold
70.2021/9/26
OE of HUST
70
3.5.2 Small-Signal Modulation
:amplitude-phase coupling parameter, ex. bulk material: 4~8; MQW: ~3
Frequency response
small-signal modulation:
Frequency chirp
Modulation:
71.2021/9/26
OE of HUST
71
72.2021/9/26
OE of HUST
72
Figure 3.21: Measured (solid curves) and fitted (dashed curves) modulation response of a 1.55-μm DFB laser as a function of modulation frequency at several bias levels.
73.2021/9/26
OE of HUST
73
Frequency chirp
3.5.3 Large-Signal Modulation
leading edge: mode frequency
shifts toward the blue side
trailing edge: mode frequency
shifts toward the red side
External modulation for high speed transmission!
74.2021/9/26
OE of HUST
74
Electro-optical Delay & Relaxation Oscillation
Pre-biased to reduce delay time!
75.2021/9/26
OE of HUST
75
Self-pulsation
不同于张弛振荡,没有阻尼,脉动频率范围为0.2~4GHz
容易发生在阈值附近和P-I特性的扭曲区
造成自脉动的机理涉及量子噪声效应、有源区的缺陷及温度感应的变化等因素
抑制这种现象主要靠控制材料的质量,尽量减少有源区的缺陷。
Operated far from kink zone!
O
P
I
76.2021/9/26
OE of HUST
76
Pattern effect
TB
I
P
biased above threshold!
“11”
“11”
78.2021/9/26
OE of HUST
78
3.6.1 Basic concept
Analog & Digital Modulation
3.6 Transmitter Design
(a) LED analog modulation (b) LED digital modulation (c) LD digital modulation
for LD, biased above threshold!
79.2021/9/26
OE of HUST
79
Digital Logic Electrical Level
0 1
TTL: 0 ~ 0.8V 2.0 ~ 5.0V
(-5V) ECL: -1.75 V -0.85 V
(+5V) PECL: +3.25 V +4.15 V
Extinction Ratio
P
P1
P0
0
t
80.2021/9/26
OE of HUST
80
Source-fiber coupling
packaging
source
fiber
Rf
coating
lensed fiber
die
submount
PD
heat sink
TEC cooler
fiber
metal shell
81.2021/9/26
OE of HUST
81
82.2021/9/26
OE of HUST
82
Butterfly packaged LD
83.2021/9/26
OE of HUST
83
External Modulator
LiNbO3 modulator in Mach-Zehnder configuration
V
84.2021/9/26
OE of HUST
84
EA
0
V=0
V(t)
T
T1
T2
λ
85.2021/9/26
OE of HUST
85
3.6.2 Driving circuit
Digital modulation circuit with APC for LD
86.2021/9/26
OE of HUST
86
射极耦合电路
三极管VT1和VT2是轮流截止和导通的,避免了载流子恢复时间的影响,因而可工作于更高的速率
射极耦合电路为恒流源,总电源电流可以保持不变,所以电源电流噪声小
D1和D2是温度补偿二极管,由于D1、D2、VT2和VT3的导通电压分别有-2.5mV/C的负温度特性,利用D1、D2对VT2、VT3的温度特性进行补偿,使温度变化时驱动电流保持恒定。
LD
87.2021/9/26
OE of HUST
87
88.2021/9/26
OE of HUST
88
Ib & Im
LD的驱动电路中偏置电流和调制电流大小的选取至关重要,偏置电流的选择合适与否直接影响激光器的高速调制输出特性。
加大直流偏置,使其接近阈值,可以减小电光延迟时间,也可使张驰振荡得到一定程度的抑制。
当激光器偏置在阈值附近时,较小的调制电流就能得到足够高的输出光脉冲,调制效率较高,而且由于偏置电流与最大电流相差不大,可以大大减小码型效应和结发热效应的不良影响。
过大的直流偏置电流会使消光比恶化,影响接收机灵敏度。
激光器恰好偏置在阈值时,散粒噪声会增强,直接影响信号的信噪比。
因此偏置电流的选取应兼顾上述各种影响,根据所用光源的特性与具体系统的要求适当选取。
