1.Scale Invariant Feature Transform (SIFT)
2.Outline What is SIFT Algorithm overview Object Detection Summary
3.Overview 1999 Generates image features, “keypoints” invariant to image scaling and rotation partially invariant to change in illumination and 3D camera viewpoint many can be extracted from typical images highly distinctive
4.Algorithm overview Scale-space extrema detection Uses difference-of-Gaussian function Keypoint localization Sub-pixel location and scale fit to a model Orientation assignment 1 or more for each keypoint Keypoint descriptor Created from local image gradients
5.Scale space Definition: where
6.Scale space Keypoints are detected using scale-space extrema in difference-of-Gaussian function D D definition: Efficient to compute
7.Relationship of D to Close approximation to scale-normalized Laplacian of Gaussian, Diffusion equation: Approximate ∂G/∂σ: giving, When D has scales differing by a constant factor it already incorporates the σ2 scale normalization required for scale-invariance
8.Scale space construction 2k2σ 2kσ 2σ kσ σ 2kσ 2σ kσ σ
9.Scale space images … first octave … … second octave … … third octave … fourth octave … …
10.Difference-of-Gaussian images … first octave … … second octave … … third octave … fourth octave … …
11.Frequency of sampling There is no minimum Best frequency determined experimentally
12.Prior smoothing for each octave Increasing σ increases robustness, but costs σ = 1.6 a good tradeoff Doubling the image initially increases number of keypoints
13.Finding extrema Sample point is selected only if it is a minimum or a maximum of these points DoG scale space Extrema in this image
14.Localization 3D quadratic function is fit to the local sample points Start with Taylor expansion with sample point as the origin where Take the derivative with respect to X, and set it to 0, giving is the location of the keypoint This is a 3x3 linear system
15.Localization Derivatives approximated by finite differences, example: If X is > 0.5 in any dimension, process repeated
16.Filtering Contrast (use prev. equation): If | D(X) | < 0.03, throw it out Edge-iness: Use ratio of principal curvatures to throw out poorly defined peaks Curvatures come from Hessian: Ratio of Trace(H)2 and Determinant(H) If ratio > (r+1)2/(r), throw it out (SIFT uses r=10)
17.Orientation assignment Descriptor computed relative to keypoint’s orientation achieves rotation invariance Precomputed along with mag. for all levels (useful in descriptor computation) Multiple orientations assigned to keypoints from an orientation histogram Significantly improve stability of matching
18.Keypoint images
19.Descriptor Descriptor has 3 dimensions (x,y,θ) Orientation histogram of gradient magnitudes Position and orientation of each gradient sample rotated relative to keypoint orientation
20.Descriptor Weight magnitude of each sample point by Gaussian weighting function Distribute each sample to adjacent bins by trilinear interpolation (avoids boundary effects)
21.Descriptor Best results achieved with 4x4x8 = 128 descriptor size Normalize to unit length Reduces effect of illumination change Cap each element to 0.2, normalize again Reduces non-linear illumination changes 0.2 determined experimentally
22.Object Detection Create a database of keypoints from training images Match keypoints to a database Nearest neighbor search
23.PCA-SIFT Different descriptor (same keypoints) Apply PCA to the gradient patch Descriptor size is 20 (instead of 128) More robust, faster
24.Summary Scale space Difference-of-Gaussian Localization Filtering Orientation assignment Descriptor, 128 elements
